XL6009 DC-DC Step-Up Boost Converter Module

Upgrade your electronics projects with the XL6009 DC-DC Step-Up Boost Converter Module — a compact, adjustable power supply solution that steps up voltage from 4.5V–32V input to a maximum of 52V output. Whether you're powering LED arrays, DIY electronics, robotics, or custom circuits, this module delivers stable, adjustable voltage with reliable efficiency.

Key Specifications

Input Voltage Range: 4.5V – 32V DC
Output Voltage Range: Adjustable up to 52V DC
Maximum Input Current: 4A
No-Load Current: Less than 18mA (at 5V input / 8V output; note: no-load current increases with higher voltage)
Chipset: XL6009 — high-efficiency switching regulator IC
Includes: SMD components pre-soldered on board
Weight: 21.33g
Customizable: Yes

Why Choose This Step-Up Module?

✅ Wide Input Range — compatible with a broad array of power sources including batteries, solar panels, and bench supplies
✅ Adjustable Output — fine-tune the output voltage to match your exact project requirements
✅ Compact & Lightweight — easy to integrate into tight enclosures or breadboard setups
✅ High Efficiency — the XL6009 IC minimizes heat generation and energy waste
✅ LED Voltmeter Display — monitor output voltage at a glance in real time
✅ SMD Construction — durable surface-mount design for long-lasting performance

Typical Applications

LED driver circuits and LED strip power supplies
DIY electronics and maker/hobbyist projects
Battery-powered boost converter setups
Adjustable bench power supplies
Robotics, Arduino, and Raspberry Pi power regulation
Solar energy harvesting and charging circuits

What's in the Box?

1 × XL6009 DC-DC Step-Up Boost Converter Module (SMD)

Related Products You May Like

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: What does the XL6009 DC-DC Step-Up Boost Converter Module do?

A: The XL6009 Step-Up Boost Converter Module takes a lower DC input voltage (4.5V–32V) and boosts it to a higher, adjustable DC output voltage of up to 52V. It is ideal for applications where you need a higher voltage than your power source provides, such as LED drivers, DIY electronics, and custom power supply circuits.

Q: How do I adjust the output voltage on this module?

A: The output voltage is adjusted using the onboard trimmer potentiometer. Use a small flathead screwdriver to turn the pot while monitoring the LED voltmeter display until you reach your desired output voltage. Always adjust with caution and keep the load connected for accurate readings.

Q: What is the maximum current this module can handle?

A: The XL6009 module supports a maximum input current of 4A. Keep in mind that output current will be lower than input current in a step-up configuration — the higher the output voltage relative to input, the lower the available output current. For best results, do not exceed the rated input current to ensure stable operation and longevity of the module.

Q: Is this module compatible with Arduino or Raspberry Pi projects?

A: Yes — the XL6009 Step-Up Module is widely used in Arduino, Raspberry Pi, and other microcontroller-based projects where a boosted supply voltage is needed. Its compact size and wide input range make it easy to integrate into custom enclosures and prototyping setups.
