XL6009 DC-DC Voltage Boost Converter Module

Keep your electronics powered at a stable output no matter what your input source delivers. The XL6009 DC-DC Boost Converter Module is a compact, highly efficient step-up regulator designed for solar panels, battery packs, DIY electronics projects, and automotive applications. With a wide input range of 5V to 32V and an adjustable output up to 35V, this module delivers consistent, reliable power where you need it most.

Why the XL6009 Boost Module?

Many 12V devices struggle when powered by variable sources such as solar panels or partially discharged batteries. This automatic voltage boosting circuit solves that challenge — regardless of whether your input is 5V, 12V, or anything in between, the adjustable output remains stable and steady. The onboard potentiometer lets you dial in your exact target voltage with precision.

Key Features

Wide Input Voltage Range: 5V – 32V DC
Adjustable Output Voltage: Up to 35V DC
High Efficiency: Up to 94% conversion efficiency
XL6009 IC: High-performance, thermally stable step-up chip
Solar Panel Compatible: Ideal for off-grid and portable solar power setups
Compact Design: Easy to integrate into enclosures, breadboards, or custom builds
Onboard Potentiometer: Simple screw-adjust output voltage tuning
Short-Circuit & Over-Temperature Protection

Ideal Use Cases

Solar power systems and off-grid charging
DIY electronics and maker projects
Battery-to-device voltage regulation
Automotive and motorcycle 12V power management
Raspberry Pi, Arduino, and microcontroller power supplies
LED driver circuits

Technical Specifications

IC Chip	XL6009
Input Voltage	5V – 32V DC
Output Voltage	Adjustable, up to 35V DC
Output Current	Up to 3A (max 4A)
Switching Frequency	400 kHz
Efficiency	Up to 94%
Module Size	~43 x 21 x 14 mm

Frequently Asked Questions

Q: What does the XL6009 DC-DC boost converter module do?

A: The XL6009 boost converter module is a step-up voltage regulator that takes a lower DC input voltage (5V–32V) and converts it to a higher, adjustable DC output voltage (up to 35V). This makes it perfect for powering 12V or higher-voltage devices from solar panels, batteries, or other variable power sources.

Q: Is the XL6009 module compatible with solar panels?

A: Yes! The XL6009 module is an excellent match for solar panel applications. Solar panels often output variable voltages depending on sunlight conditions. This module's wide input range and automatic boosting capability ensure your connected device receives a stable, consistent output voltage regardless of fluctuations in solar energy production.

Q: How do I set the output voltage on this boost module?

A: The output voltage is adjusted using the onboard multi-turn potentiometer. Simply use a small screwdriver to turn the adjustment screw while monitoring the output with a multimeter until you reach your desired voltage. Always set and verify your output voltage before connecting sensitive electronics.

Q: What projects is this module best suited for?

A: This module is ideal for DIY electronics, Arduino and Raspberry Pi power supplies, solar off-grid systems, automotive voltage boosting, LED driver circuits, and any project where you need to step up a lower DC voltage to a stable, higher level.
