W5500 TCP/IP Ethernet Network Interface Module – WIZ820IO Compatible

The W5500 Ethernet Network Module is a compact, high-performance hardware TCP/IP network interface designed for seamless integration into microcontroller-based projects. Built on the trusted W5500 chip, this module is fully compatible with the WIZ820IO standard, making it a go-to choice for makers, engineers, and developers who need reliable wired Ethernet connectivity.

Key Features

Full Hardware TCP/IP Stack: Offloads network processing from your microcontroller with the W5500's built-in TCP/IP stack — supporting TCP, UDP, ICMP, IPv4, ARP, IGMP, and PPPoE protocols.
SPI Interface: Communicates via high-speed SPI (up to 80 MHz), making it easy to connect to Arduino, STM32, Raspberry Pi, and other popular platforms.
8 Independent Sockets: Supports up to 8 simultaneous independent connections for versatile multi-channel communication.
WIZ820IO Compatible: Drop-in compatible with WIZ820IO pin layout for effortless upgrades and substitutions in existing designs.
10/100 Mbps Ethernet: Delivers fast and stable wired network speeds suitable for IoT devices, data logging, remote monitoring, and more.
3.3V I/O Voltage: Low-voltage operation ideal for modern microcontrollers, with an integrated LDO regulator for reliable power management.
Compact Form Factor: Small footprint makes it easy to embed into custom PCBs and enclosures.
RJ45 Connector Included: Ready to plug into any standard Ethernet network — no additional adapters required.

Specifications

Chip: WIZnet W5500
Protocol Support: TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE
SPI Clock Speed: Up to 80 MHz
Number of Sockets: 8
Network Speed: 10/100 Mbps
Operating Voltage: 3.3V
Interface: SPI (Mode 0, 3)
Connector: RJ45

Ideal Applications

Arduino / AVR / STM32 / ESP-based Ethernet projects
IoT sensor nodes and data loggers
Remote monitoring and control systems
Industrial automation and embedded networking
Smart home and DIY electronics prototyping
