TTL to RS485 Converter Module | UART Serial Level Conversion

TTL to RS485 Converter Module – UART Serial Level Conversion

Upgrade your embedded projects and serial communication setups with this compact TTL to RS485 Converter Module. Designed for seamless bidirectional level conversion between TTL (3.3V/5V) UART interfaces and RS485 differential signal lines, this module is an essential component for engineers, hobbyists, and developers working with microcontrollers, PLCs, sensors, and industrial communication systems.

With automatic flow control and wide operating temperature range (-40°C to +85°C), this module is built for dependable performance in both desktop and field environments. Its ultra-compact SMD form factor (just 1.5 × 4.3 cm, 1.69g) makes it easy to integrate into tight enclosures or breadboard prototypes.

Key Features

• Bidirectional Conversion: Effortlessly converts TTL UART signals to RS485 and back, enabling reliable long-distance serial communication.
• Dual Voltage Support: Compatible with both 3.3V and 5V power supplies — works with a wide range of microcontrollers including Arduino, ESP32, STM32, and Raspberry Pi.
• Automatic Flow Control: Built-in automatic direction switching removes the need for manual RTS/CTS signal management.
• Wide Temperature Range: Operates reliably from -40°C to +85°C, suitable for industrial and outdoor applications.
• Ultra-Compact SMD Design: Measures just 1.5 × 4.3 cm and weighs only 1.69g — perfect for space-constrained builds.
• Customizable Quantity: Available in 1-piece, 5-piece, or 10-piece sets to match your project scale.

Specifications

What's in the Box

• TTL to RS485 Converter Module(s) (quantity as selected: 1pcs / 5pcs / 10pcs)

Perfect For

• Arduino, ESP8266/ESP32, STM32, and Raspberry Pi projects
• PLC and industrial controller interfacing
• Long-distance serial data transmission
• Smart home automation and sensor networks
• DIY electronics and prototyping
