NE555 Multi Harmonic Oscillator Circuit Kit – Double Flash DIY

NE555 Multi Harmonic Oscillator Circuit Kit

Build and explore the fundamentals of electronic oscillation with this NE555 Multi Harmonic Oscillator Kit. Centered around the classic NE555 timer IC, this astable (non-steady-state) circuit module produces a continuous oscillating output — perfect for driving double flash lamp effects, learning circuit design, and hands-on electronics experimentation.

Whether you're a hobbyist, electronics student, or maker, this compact SMD module is a fantastic way to understand timer-based oscillator circuits while producing a visible, satisfying result with flashing LED or lamp outputs.

Key Features

• NE555 Timer IC – Industry-standard 555 timer configured in astable (free-running) mode for continuous oscillation
• Double Flash Lamp Output – Drives a dual-lamp or dual-LED flashing circuit for a classic visual oscillator demonstration
• SMD Package Design – Compact surface-mount component layout for a clean, space-efficient build
• DIY / Educational Kit – Ideal for electronics learning, school projects, maker labs, and hobbyist builds
• Customizable – Supports component-level customization to adjust frequency and duty cycle
• New Condition – Ships brand new, 1 piece per order

Specifications

What Is a 555 Astable Oscillator Circuit?

The NE555 timer in astable mode operates as a free-running oscillator — it continuously switches between HIGH and LOW states without any external trigger. This makes it the go-to circuit for generating square waves, clock pulses, and visual flashing effects. This kit demonstrates that principle in a compact, hands-on module.

Great Pairings for Your DIY Projects

Complete your electronics toolkit with other quality components from our store:

• Round Aluminum Wire 1mm–3mm | DIY Jewelry Making Wire – Versatile wire for creative project builds and wiring
• 4/6mm CCB Flat Round Spacer Beads DIY Jewelry Making 100-200pcs – Perfect for mixed-media maker and craft projects

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: What does the NE555 Multi Harmonic Oscillator Kit do?

A: This kit uses the NE555 timer IC wired in astable (non-steady-state) mode to generate a continuous oscillating signal that drives a double flash lamp or LED output. It's a classic electronics circuit used for learning oscillation, timing, and pulse generation concepts.

Q: Is this kit suitable for beginners in electronics?

A: Yes — the NE555 oscillator is one of the most widely taught circuits in electronics education. This SMD module is an excellent hands-on introduction to timer ICs, astable circuits, and oscillator theory for students, hobbyists, and makers at all skill levels.

Q: Can I modify the oscillation frequency of this circuit?

A: Yes. The frequency and duty cycle of a 555 astable circuit are determined by the values of the resistors and capacitor connected to the timing pins. By swapping these components, you can adjust how fast or slow the flash lamp oscillates, making it a highly customizable learning platform.

Q: How many pieces are included per order?

A: Each order includes 1 piece (1 PCS) of the NE555 Multi Harmonic Oscillator Circuit Kit.
