MAX3485 TTL to RS485 Module | USART Serial Communication

MAX3485 TTL to RS485 USART Communication Module

The MAX3485 TTL to RS485 Module is a compact, reliable serial communication converter designed for seamless integration into microcontroller projects, industrial control systems, and embedded electronics. Whether you're building a multi-device network or simply bridging TTL logic levels to RS485 differential signaling, this module delivers stable, low-noise data transmission for both hobbyists and professionals.

Key Features

• TTL to RS485 Conversion: Converts standard USART/TTL logic signals to RS485 differential signals for long-distance, noise-resistant communication.
• Multi-machine Communication: Supports parallel multi-device bus topologies — connect multiple nodes on a single RS485 line.
• Compact Module Design: Small footprint makes it easy to integrate into existing PCB layouts or prototype breadboards.
• Based on MAX3485 IC: Uses the industry-trusted MAX3485 transceiver chip for reliable half-duplex RS485/RS422 communication.
• Low Power Consumption: Efficient design suited for battery-powered or low-energy embedded applications.
• Wide Compatibility: Works with Arduino, Raspberry Pi, STM32, ESP32, and other USART-capable microcontrollers.
• Flexible Quantity Options: Available as 1PCS, 5PCS, or 10PCS — stock up and save.

Specifications

• IC: MAX3485
• Interface: TTL / USART to RS485
• Communication Mode: Half-duplex
• Operating Voltage: 3.3V / 5V compatible
• Quantity Options: 1PCS, 5PCS, 10PCS
• Customizable: Yes

What's in the Box?

• MAX3485 TTL to RS485 Module (quantity per your selected option)

Perfect For

• Arduino, ESP32, and STM32 RS485 communication projects
• Industrial automation and PLC bus networking
• Modbus RTU serial communication setups
• Long-distance sensor data transmission
• Multi-node serial bus systems
