Logic Pulser Analyzer Detecting Probe – 5V & 3.3V

Take the guesswork out of circuit diagnostics with this compact Logic Pulser Analyzer Detecting Probe. Designed to work seamlessly at both 5V and 3.3V logic levels, this handy module is the go-to tool for electronics hobbyists, makers, students, and professionals who need fast, reliable logic signal detection on the bench or in the field.

Key Features

Dual Voltage Support: Compatible with both 5V TTL and 3.3V CMOS logic systems — no need for multiple probes.
Instant Signal Detection: Quickly identifies HIGH, LOW, and pulse states on digital circuits for fast troubleshooting.
Compact & Portable: Pen-style probe form factor fits easily in a tool kit, making it ideal for on-the-go circuit testing.
Plug & Play: No complex setup required — connect and start probing right away.
Wide Operating Temperature: Rated for 0–120°C, suitable for a broad range of working environments.
SMD Package: Space-saving module design for clean, professional integration.
Quantity: Includes 1 logic pulser probe module.

Who Is It For?

Whether you're debugging a microcontroller project, verifying signal lines on a PCB, learning digital electronics, or working on DIY automation builds, this logic probe simplifies your workflow. It pairs perfectly with breadboard prototypes, Arduino or Raspberry Pi projects, and any digital circuit requiring fast level verification.

Specifications

Supply Voltage: 5V / 3.3V
Type: Logic Pulser/Analyzer Module
Package: SMD
Operating Temperature: 0–120°C
Condition: New
Quantity: 1
