LM3914 10-Segment Battery Capacity Indicator Module LED Bar

Monitor your battery levels at a glance with the LM3914 10-Segment Battery Capacity Indicator Module. Designed for makers, hobbyists, and electronics enthusiasts, this compact module provides a clear, real-time visual readout of battery charge levels using a 10-LED bar or dot display. Whether you're building a custom power monitoring system or adding a charge indicator to your DIY project, this module delivers reliable, precise readings every time.

Key Features

• 10-Segment LED Display: Instantly visualize battery charge level with a bright 10-LED bar graph or single-dot display mode
• Wide Measurement Range: Compatible with universal 2.4V–20V batteries, including 3.7V lithium, 12V lead-acid, and more
• Dual Display Modes: Switch between multi-light bar strip display (42mA) or energy-efficient single-light dot display (4mA)
• Adjustable Design: Fully customizable output thresholds to suit a wide variety of battery types and project requirements
• Compact PCB Form Factor: Small 2.6 × 4.9 cm board fits easily into enclosures or custom builds
• Wide Operating Temperature: Rated for use from -40°C to +85°C — suitable for demanding environments
• Low Supply Voltage: Operates at 3.7V supply, ideal for battery-powered builds
• SMD Package: Surface-mount design for clean, professional-looking PCB integration
• LED Color Options: Available in green or mixed color (random assortment)

Specifications

Perfect For

• DIY battery monitoring projects
• Lithium-ion and lead-acid battery charge indicators
• RC vehicles, solar power systems, and portable power banks
• Arduino, Raspberry Pi, and custom electronics builds
• Robotics and maker projects

Related Products You May Like

Complete your electronics or DIY projects with these complementary items from our store:

• Round Aluminum Wire 1mm–3mm | DIY Jewelry Making Wire
• Glow in the Dark Natural Stone Round Beads | DIY Jewelry Making

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: What battery types is the LM3914 10-Segment Battery Capacity Indicator Module compatible with?

A: This LM3914 module is compatible with a wide range of battery types, including 3.7V lithium-ion, 12V lead-acid, and virtually any battery with a voltage between 2.4V and 20V. Its adjustable threshold design makes it highly versatile for different battery chemistries and project needs.

Q: What is the difference between bar display mode and dot display mode?

A: In bar display mode, all LEDs up to the current charge level illuminate simultaneously, giving you a clear bar-graph readout — this mode draws approximately 42mA. In dot display mode, only a single LED lights up to indicate the charge level, which is much more energy-efficient at just 4mA, making it ideal for battery-powered applications where conserving power is important.

Q: How do I connect the LM3914 Battery Indicator Module to my project?

A: The module connects directly to your battery's positive and negative terminals for voltage sensing, and requires a 3.7V supply voltage to operate. The PCB's compact 2.6 × 4.9 cm footprint makes it easy to integrate into custom enclosures or mount on a breadboard. Refer to the LM3914 datasheet for detailed wiring and threshold adjustment guidance.

Q: Can I adjust the voltage measurement range on this module?

A: Yes — the LM3914 module features an adjustable design, allowing you to calibrate the upper and lower voltage thresholds to match your specific battery type. This makes it suitable for a broad range of applications, from small single-cell lithium packs to larger 12V lead-acid systems.
