DIY NE555 CD4017 Running LED Flow Light Production Kit

Build your own mesmerizing running LED light display with this hands-on DIY electronic kit! Featuring the classic NE555 timer IC and CD4017 decade counter, this production suite creates a smooth, flowing LED light sequence that's perfect for electronics enthusiasts, students, hobbyists, and makers of all skill levels.

Why You'll Love This Kit

Engaging Build Experience: Assemble your own running LED flow light from scratch — a fantastic way to learn circuit design, SMD soldering, and IC-based timing circuits.
Classic IC Combination: Uses the widely studied NE555 timer (clock generator) paired with the CD4017 decade counter to drive LEDs in a sequential running pattern.
SMD Components Included: Each order includes SMD components for a compact, professional-looking finished board.
Multiple Quantity Options: Available in 1-piece, 5-piece, and 10-piece sets — ideal for classrooms, workshops, or bulk hobby projects.
3 Color Options: Choose from 3 LED color variants to customize your light display.
Customizable Design: Fully customizable to suit your project needs — adjust timing, LED count, and layout.
Great for Learning & Decor: Use it as a science/electronics learning project or as an eye-catching decorative light display once assembled.

How It Works

The NE555 timer IC generates a clock pulse signal, which feeds into the CD4017 decade counter IC. The CD4017 steps through its 10 output pins sequentially with each clock pulse, lighting up each LED in turn to create the classic "running light" or "chasing light" effect. It's a timeless beginner-to-intermediate electronics circuit that teaches real-world IC principles.

Product Specifications

ICs Used: NE555 Timer + CD4017 Decade Counter
Components: SMD (Surface Mount Device)
Available Quantities: 1pcs, 5pcs, 10pcs
LED Color Options: 3 color variants available
Application: DIY electronics, education, decorative lighting
Customized: Yes

Perfect For

Electronics students and hobbyists
STEM education projects and classroom demonstrations
Maker spaces and electronics workshops
Decorative LED light displays
Practicing SMD soldering skills

Explore More DIY & Electronics Products

Looking for more components to complete your builds? Check out our Round Aluminum Wire for DIY Making for crafting and wiring projects, or browse our CCB Flat Round Spacer Beads for DIY Projects. For more creative kits, explore our Glow in the Dark Round Beads for DIY Making.

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: What does the DIY NE555 CD4017 Running LED Flow Light Kit include?

A: Each kit includes all necessary SMD components to assemble a running LED flow light circuit. The NE555 timer IC and CD4017 decade counter IC work together to create a smooth sequential LED chasing light effect. Available in 1pcs, 5pcs, or 10pcs quantities, with a choice of 3 LED colors.

Q: Is this kit suitable for beginners in electronics?

A: This kit is well-suited for beginner-to-intermediate electronics enthusiasts. It's a classic learning circuit commonly used in electronics education to demonstrate IC timer and counter functions. Basic SMD soldering experience is helpful, and it makes an excellent hands-on project for students and hobbyists.

Q: What power supply does the NE555 CD4017 LED flow light kit require?

A: The NE555 and CD4017 ICs typically operate on a standard DC supply voltage (commonly 5V–15V depending on your specific board configuration). Please review the included documentation for the exact voltage requirements of your kit variant before powering it up.

Q: Can I use this kit as a decorative light display after assembly?

A: Absolutely! Once assembled, the running LED flow light creates an attractive sequentially animated light display that can be used as a decorative accent in your home, workspace, or hobby room. Its compact SMD design gives it a sleek, professional appearance.
