Digital MIDI Adapter Board Module – High-Speed Serial Communication

Take your music production and electronics projects to the next level with this compact Digital MIDI Adapter Plate Board. Built on a quality PCB, this versatile module bridges MIDI devices with serial communication ports, enabling real-time data transfer between synthesizers, keyboards, controllers, and more. Whether you're building a custom MIDI controller or expanding your studio setup, this adapter board delivers reliable, high-speed performance in a compact footprint.

Key Features

High-Speed MIDI Data Transmission: Transmits MIDI signals at high speed for timely, accurate data transfer — ideal for real-time control and live performance setups.
Multi-Channel Support: Handles multiple MIDI channels simultaneously, enabling multi-track recording and flexible signal routing. Each channel independently sends and receives MIDI messages.
Universal Compatibility: Works with MIDI-compliant devices including synthesizers, keyboards, and controllers for seamless signal transmission and processing.
User-Friendly Design: Features standard pin arrangements and sockets for straightforward connection to other hardware devices — no soldering expertise required for most setups.
Programmable Control: Program MIDI channels, configure message types, manage interrupts, and tailor the module to your specific application requirements.
Compact Form Factor: Measures approximately 57.4 × 53.1 mm (2.26 × 2.09 in), fitting neatly into enclosures, breadboards, or custom builds.
PCB Construction: Durable printed circuit board (PCB) material ensures longevity and consistent electrical performance.

Specifications

Material	PCB
Dimensions	Approx. 57.4 × 53.1 mm / 2.26 × 2.09 in
Assembly Required	No
Ships From	CN (Made in China)

Package Includes

1 × MIDI Adapter Board Module

Notes

Please allow 1–2 cm variance due to manual measurement.
Colors may vary slightly between monitors and actual product.

Frequently Asked Questions

Q: What does the Digital MIDI Adapter Board Module do?

A: This MIDI adapter board provides a serial communication interface between MIDI-compatible devices such as synthesizers, keyboards, and controllers. It features standard pin arrangements and sockets for easy connection, supports high-speed data transmission, and allows programmable control of MIDI channels and message types — making it a versatile component for music production and electronics projects.

Q: How many MIDI channels does this adapter board support?

A: The board supports multiple MIDI channels simultaneously, allowing you to send and receive independent MIDI messages on each channel. This makes it well-suited for multi-track recording setups or complex signal routing scenarios where flexibility and scalability are important.

Q: What devices is this MIDI adapter board compatible with?

A: This adapter board is compatible with any standard MIDI-compliant device, including synthesizers, digital keyboards, MIDI controllers, drum machines, and other hardware that communicates via MIDI protocol. Its standard pin layout ensures broad compatibility across a wide range of musical and electronic equipment.

Q: What are the dimensions of the MIDI adapter board?

A: The board measures approximately 57.4 × 53.1 mm (2.26 × 2.09 inches), making it compact enough to integrate into custom enclosures, prototyping boards, or studio equipment builds with ease.
