DB207 / DB207S Bridge Rectifier Diodes – DIP-4 Package, 2A 1000V

Get reliable AC-to-DC conversion with this pack of DB207 / DB207S Single-Phase Bridge Rectifier Diodes. Housed in a compact DIP-4 through-hole package, each diode delivers a peak reverse voltage of 1000V and a continuous forward current of 2A, making them a staple component for power supply circuits, battery chargers, inverters, and general electronics projects.

Key Specifications

Model: DB207 / DB207S
Package: DIP-4 (Through-Hole)
Maximum Repetitive Peak Reverse Voltage: 1000V
Average Rectified Forward Current (If): 2A
Configuration: Single-Phase Full-Wave Bridge Rectifier
Quantity: 10 pieces per lot

Why Choose the DB207 Bridge Rectifier?

✅ High Voltage Rating: 1000V peak reverse voltage handles demanding AC input sources with ease.
✅ Compact DIP-4 Form Factor: Easy to solder onto standard PCBs and breadboards — perfect for prototyping and production.
✅ Versatile Applications: Ideal for power supplies, motor drivers, battery chargers, LED drivers, and DIY electronics builds.
✅ Value Pack: 10 pieces per lot ensures you always have spares on hand for your projects.
✅ Consistent Performance: Manufactured to tight tolerances for reliable, repeatable circuit behavior.

Common Applications

AC-to-DC power supply rectification circuits
Battery charger modules
Transformer secondary rectifiers
Motor control and inverter circuits
DIY electronics and hobbyist projects
PCB assembly and repair

Related Products You May Like

Pair these rectifier diodes with other useful electronics components and accessories from our store:

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: What does a DB207 bridge rectifier diode do?

A: The DB207 is a single-phase full-wave bridge rectifier that converts alternating current (AC) into direct current (DC). It uses four internal diodes arranged in a bridge configuration to ensure current flows in one direction, producing a smooth, usable DC output from an AC source — an essential building block in power supply design.

Q: What is the difference between DB207 and DB207S?

A: The DB207 and DB207S are functionally equivalent bridge rectifier diodes with the same electrical specifications (2A, 1000V). The "S" suffix typically denotes a slight variation in the lead or body finish from certain manufacturers, but both are pin-compatible in DIP-4 footprints and can be used interchangeably in most circuit designs.

Q: What circuits are DB207 DIP-4 bridge rectifiers commonly used in?

A: DB207 bridge rectifiers are widely used in AC-to-DC power supply circuits, transformer-based battery chargers, low-to-medium power motor drivers, LED power drivers, and general-purpose PCB assemblies requiring full-wave rectification at up to 1000V peak reverse voltage and 2A forward current.

Q: Are these diodes suitable for breadboard prototyping?

A: Yes. The DIP-4 through-hole package features standard pin spacing that fits directly into breadboards and perfboards, making DB207 bridge rectifiers an excellent choice for prototyping, testing, and small-batch PCB production.
