BT-09 Bluetooth 4.0 BLE Serial Port Module – CC2541 Chip, HM-10 Compatible

The BT-09 Bluetooth 4.0 BLE Module is a compact, low-energy wireless serial communication module built around the reliable Texas Instruments CC2541 chip. Fully compatible with the popular HM-10 module, it's the go-to choice for makers, engineers, and hobbyists who need a drop-in Bluetooth Low Energy (BLE) solution for their microcontroller projects.

Whether you're building a wireless sensor network, adding BLE connectivity to an Arduino or Raspberry Pi project, or prototyping a custom IoT device, the BT-09 delivers stable serial communication with minimal power draw — right out of the box.

Key Features

Bluetooth 4.0 BLE — Ultra-low power consumption, ideal for battery-powered applications
CC2541 Chipset — Proven, high-performance BLE SoC from Texas Instruments
HM-10 Compatible — Drop-in replacement; use the same firmware commands and pinout
Serial UART Interface — Simple TX/RX communication; plug into any microcontroller with ease
AT Command Support — Fully configurable via standard AT commands (baud rate, device name, etc.)
Compact Form Factor — Easy to embed into tight enclosures and custom PCBs
Broad Compatibility — Works with Arduino, Raspberry Pi, STM32, ESP32, and more

Technical Specifications

Bluetooth Version: 4.0 BLE (Bluetooth Low Energy)
Chip: CC2541 (Texas Instruments)
Interface: UART Serial (TTL)
Operating Voltage: 3.3V
Communication Protocol: AT Commands
HM-10 Pin & Firmware Compatible

What Can You Build With It?

The BT-09 module is perfect for a wide range of DIY and professional projects:

Wireless data logging and sensor monitoring
Smartphone-controlled robotics and automation
Custom BLE peripheral devices
Home automation and IoT prototyping
Wearable electronics with low-power requirements

Frequently Asked Questions

Q: What is the BT-09 Bluetooth 4.0 BLE Module and what does it do?

A: The BT-09 is a compact Bluetooth Low Energy (BLE 4.0) serial communication module based on the CC2541 chip. It enables wireless UART serial data transmission between a microcontroller (such as Arduino or Raspberry Pi) and a smartphone or other BLE-enabled device. It is HM-10 compatible, making it an easy drop-in upgrade or replacement for existing BLE serial projects.

Q: Is the BT-09 module compatible with Arduino and Raspberry Pi?

A: Yes! The BT-09 uses a standard UART TTL serial interface and supports AT commands, making it fully compatible with Arduino, Raspberry Pi, STM32, ESP32, and virtually any microcontroller with a serial port. Simply connect TX, RX, VCC (3.3V), and GND to get started.

Q: How is the BT-09 different from or better than the HM-10 module?

A: The BT-09 is designed to be pin-compatible and firmware-compatible with the HM-10, meaning you can use the same AT commands and wiring. The CC2541 chipset provides a well-established, stable BLE 4.0 platform. It serves as a cost-effective alternative or direct replacement for HM-10 modules in most projects.

Q: What operating voltage does the BT-09 module require?

A: The BT-09 module operates at 3.3V. If your microcontroller outputs 5V logic (e.g., standard Arduino Uno), a simple logic level converter or voltage divider on the TX line is recommended to protect the module.
