AS5048A 14-Bit Magnetic Rotary Encoder Module SPI PWM

AS5048A 14-Bit Magnetic Rotary Encoder Module – SPI & PWM Angle Position Detection

The AS5048A 14-Bit Magnetic Rotary Encoder Module delivers ultra-precise, contactless angle and position detection using magnetic sensing technology. With 16,384 resolution steps per revolution (14-bit), this compact sensor board is ideal for robotics, motor feedback systems, CNC machines, servo controllers, and any project demanding high-accuracy rotational measurement. It communicates via both SPI and PWM interfaces, making it easy to integrate with Arduino, Raspberry Pi, STM32, and other popular microcontrollers.

Key Features

• 14-Bit Resolution: 16,384 positions per revolution for pinpoint angle detection
• Dual Interface: SPI and PWM output for flexible microcontroller integration
• Contactless Magnetic Sensing: No mechanical wear — long-lasting and reliable
• Compact PCB Design: Easy to mount in tight spaces within your project enclosure
• Wide Compatibility: Works with Arduino, Raspberry Pi, STM32, ESP32, and more
• Available in Multi-Packs: Choose from 1PC, 2PCS, 5PCS, or 10PCS to suit your project scale
• Polymer Construction: Lightweight and durable module board

Specifications

• Chip: AS5048A
• Resolution: 14-Bit (16,384 steps/revolution)
• Interface: SPI, PWM
• Application: Angle position detection, motor control, robotics, automation
• Material: Polymer PCB
• Pack Options: 1PC, 2PCS, 5PCS, 10PCS

Ideal Applications

• Brushless motor commutation and feedback control
• Robotics joint angle sensing
• CNC machine axis position tracking
• Pan-tilt camera gimbal systems
• Industrial automation and servo systems
