5V Step Up Power Module Board with LED Indicators – 10-Pack for DIY Projects

Build your own mobile power bank or custom charging device with this compact 5V Step Up Power Module Board. Designed as a complete single-chip solution, each board integrates charging management, discharging management, power detection, LED status indicators, and a full suite of built-in safety protections — everything you need for reliable DIY electronics projects.

Key Features

All-in-One Single-Chip Design: Combines charging management, discharging management, power detection, LED indication, and protection functions on one compact board.
Built-In Charging & Discharging Power MOS: Supports adjustable charging current; both charging and discharging currents operate at 1A.
Comprehensive Safety Protections: Includes constant-temperature charging mode, over-temperature protection, over-charge & over-discharge protection, output overvoltage protection, output overload protection, and output short-circuit protection.
LED Status Indicators: Red light flashes during charging, solid red when fully charged, and blue light flashes during discharge — easy at-a-glance monitoring.
Dual Port Options: Available with Type-C or Micro USB input; USB output port included. Perfect for customizing your own power adapter or charging accessory.
ABS + Metal Construction: Durable and lightweight for long-lasting use in your builds.

Specifications

Material	ABS + Metal
Input Type	Type-C or Micro USB (optional)
Output Voltage	5V (Step-Up)
Charge / Discharge Current	1A / 1A
Size	Approx. 20mm / 0.78 inch
Package Quantity	10pcs per set
Ships From	China

Package Includes

10 × Battery Charging Board (5V Step Up Power Module)

Please Note

Please allow 1–2cm measurement variation due to manual measuring.
Slight color differences may occur due to different display resolutions.

Complete Your DIY Project

Looking for more components and materials for your DIY creations? Check out these related items in our store:

Learn more: EPA guidance on lithium-ion battery handling

Frequently Asked Questions

Q: What is the 5V Step Up Power Module Board used for in DIY projects?

A: The 5V Step Up Power Module Board is designed for building custom mobile power banks, portable chargers, and other DIY electronics projects. It integrates charging management, discharging management, power detection, LED indicators, and full safety protections into one compact chip solution, making it ideal for makers and electronics hobbyists.

Q: What input types are supported by this power module board?

A: This power module board is available in two input variants — Type-C and Micro USB — so you can choose whichever connector fits your DIY build. Both versions include a USB output port for charging connected devices.

Q: What safety protections are built into this 5V Step Up Power Module?

A: The module features a comprehensive set of built-in safety functions including constant-temperature charging mode, over-temperature protection, over-charge and over-discharge protection, output overvoltage protection, output overload protection, and output short-circuit protection — giving you peace of mind in your DIY electronics builds.

Q: How do the LED indicators work on this power module board?

A: The LED indicators provide clear visual status updates: the red light flashes while the battery is charging, the red light stays solid when fully charged, and the blue light flashes when the battery is in discharge mode. This makes it easy to monitor your battery status at a glance.
