4 Channel MOSFET PWM Pulse Trigger Switch Controller Board

4 Channel MOSFET PWM Pulse Trigger Switch Controller Board

Take precise control of motors, LED lights, and other DC loads with this versatile 4 Channel MOSFET PWM Pulse Trigger Switch Controller Board. Featuring an integrated optocoupler (opto-isolator) for signal isolation, this module delivers clean, reliable switching across four independent channels — perfect for hobbyists, engineers, and makers building automation projects, lighting rigs, or motor control systems.

Key Features

• 4 Independent Channels: Control up to four separate circuits simultaneously with isolated pulse trigger inputs.
• Wide Supply Voltage Range: Operates from 3.7V to 27V DC, compatible with a broad range of power supplies and battery systems.
• PWM Signal Control: Supports Pulse Width Modulation for smooth speed control of DC motors and dimming of LED lights.
• Optocoupler / Opto-Isolator Protection: Built-in optical isolation protects your microcontroller or signal source from high-power load interference.
• Compact SMD Package: Surface-mount design keeps the board small and easy to integrate into enclosures and custom builds.
• Wide Operating Temperature: Rated for 0–200°C, suitable for demanding environments.
• Customizable Quantity: Available in 1PC, 2PCS, or 5PCS packs to suit your project scale.

Specifications

Common Applications

• DC motor speed control and direction switching
• LED light dimming and strip control
• Arduino, Raspberry Pi, and other microcontroller PWM output stages
• Solenoid valve and relay replacement circuits
• Home automation and DIY electronics projects
